| PTZ Camera |
|
| Image Sensor |
1/1.8″ CMOS |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.0008Lux@ (F1.5, AGC ON) |
| Shutter Time |
1s to 1/100,000s |
| Day & Night |
Dual IR Cut Filter |
| Wide Dynamic Range |
140dB |
| Focal Length |
6mm～264mm |
| Digital Zoom |
16× |
| Zoom Speed |
<5s |
| Angle of View |
Horizontal filed of view: 61.2° (w)～2° (t) |
| Aperture Range |
F1.5~F4.8 |
| Pan Range |
360° |
| Pan Speed |
Pan Manual Speed: 0.1°~160°/s, Pan Preset Speed: 200°/s |
| Tilt Range |
-16°~90° (Auto flip) |
| Tilt Speed |
Tilt Manual Speed: 0.1°~120°/s, Tilt Preset Speed: 120°/s |
| 3D Position |
Yes |
| Presets |
500 |
| Preset Accuracy |
±0.3° |
| Scan |
8 |
| Cruise |
16, up to 32 presets per cruise |
| Pattern |
8, each with 600s memory or 1000 orders |
| Power-off Memory |
Yes |
| RS-485 Protocols |
DOME_PELCO_D, DOME_PELCO_P, DOME_PLUS |
| Max. Resolution |
1920×1080 |
| Main Stream |
PAL: 50fps (1920×1080, 1280×960, 1280×720) |
| NTSC: 60fps (1920×1080, 1280×960, 1280×720) |
| Sub Stream |
PAL: 25fps (704×576, 704×288, 352×288) |
| NTSC: 30fps (704×480, 704×240, 352×240) |
| Third stream |
PAL: 25fps (1920×1080, 1280×960, 1280×720, 640×480, 704×576, 352×288) |
| NTSC: 30fps (1920×1080, 1280×960, 1280×720, 640×480, 704×480, 352×240) |
| Panaromic Camera |
|
| Image Sensor |
1/1.8″ CMOS |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.01Lux@ (F2.2, ACG ON) |
| Shutter Time |
1s to 1/100,000s |
| Focal Length |
5mm |
| Aperture |
F2.2 |
| Angle of View |
Horizontal: 360°, Verticle: 74° |
| Max. Resolution |
(4096 × 1800)*2ch @30fps |
| Main Stream |
PAL: 25fps 2×(4096×1800, 3840×1680, 2720×1192) |
| NTSC: 30fps 2×(4096×1800, 3840×1680, 2720×1192) |
| Sub Stream |
PAL: 25fps (704×320) |
| NTSC: 30fps (704×320) |
| Third Stream |
PAL: 25fps (1280×560) NTSC: 30fps (1280×560) |
| Illuminator |
|
| IR LEDs |
N/A |
| IR Range |
N/A |
| White LEDs |
4 |
| Laser |
Yes |
| Laser Distance |
500m |
| Compression Standard |
|
| Video Compression |
S 265/H.265/H.264/M-JPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression |
G.711A/G.711U/ADPCM/AAC |
| Audio Bit Rate |
8K~48Kbps |
| Feature |
|
| Alarm Trigger |
Harsh Voice Alarm, Motion Detection, Mask Alarm, Port Alarm, Network Disable Alarm, IP Conflict, MAC Conflict Detection |
| Video Analytics |
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking, Face Detection, People Counting, Crowed, On Duty Detection, Video Abnormal, Audio Abnormal, Heatmap |
| Early Warning(EW) |
Yes |
| Auto-Tracking |
Yes |
| Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement |
BLC/3D DNR/HLC |
| ROI |
7 Dynamic Areas for Both Main and Sub Stream, support auto-tracking ROI |
| OSD |
16×16, 24×24,32×32, 48×48, 64×64, 96×96, adaptable size, Letters Such as Week, Date, Time, Total 5 Regions |
| Picture Overlay |
Yes |
| Privacy Mask |
Yes |
| Smart Defog |
Yes |
| Network |
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, MULTICAST, UPnP, FTP, IPV4, NTP, RTSP, SMTP, IGMP, QoS, PPPoE |
| System Compatibility |
ONVIF (PROFILE S), SDK, CGI |
| ANR |
Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection (Only Support Tiandy ANR NVR) |
| Remote Connection |
≤7 |
| Client |
Easy7, EasyLive |
| Web Version |
Web5 |
| Interface |
|
| Communication Interface |
1 RJ45 10M/100M/1000M self adaptive Ethernet port |
| Audio |
1/1 |
| Alarm |
8/2 |
| Reset Button |
Yes |
| On-board storage |
Built-in MicroSD card slot, up to 128 GB |
| RS-485 |
Yes |
| BNC |
Yes |
| Wiper |
N/A |
| General |
|
| Firmware Version |
NVSS_V15.2.0.20180828 |
| Web Client Language |
5 languages
English, Korean, Turkish, Simple Chinese, Traditional Chinese |
| Operating Conditions |
-30°~65°C, 0-95% RH |
| Power Supply |
AC24V±15% |
| Power Consumption |
102W (IR OFF), 119W (IR ON ) |
| Protection |
IP66 |
| Heater |
N/A |
| Dimensions |
Φ358×568 mm (Φ14.09×22.36 inch) |
| Weight |
17kg (37.48lb) |
