2MP Battery Wifi Magnetic Color MakerTC-C32CN Bullet Camera
- Metal+plastic housing
- Up to 4MP,2560×1440@20fps
- S+265/H.265/H.264B/H.264M/H.264H
- Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR
- IR range up to 50m
- Built-in Mic, Built-in Speaker
- Support microSD/microSDHC/microSDXC card,up to 512GB
- Operating conditions -30℃~60℃(-22℉~140℉), ≤95%RH
- DC12V±25%,Max. 7.5W
- IP67
- Description
- Additional information
Description
|
Camera |
|
|
Image Sensor |
1/2.9″CMOS |
|
Min. Illumination |
Color:0.02Lux@(F2.0,AGC ON),B/W:0Lux with IR |
|
Shutter Time |
1s~1/100000s |
|
Day&Night |
IR-cut filter with auto Switch (ICR) |
|
Smart IR |
Yes |
|
WDR |
120dB |
|
S/N |
>50dB |
|
Angle Adjustment |
0~360°(P); 0~75°(T); 0~360°(R) |
|
Lens |
|
|
Lens Type |
Fixed focal lens |
|
Focal Length |
2.8mm |
|
Lens Mount |
M12 |
|
Aperture Range |
F1.6 |
|
Aperture Type |
Fixed |
|
Field of View |
103.8°(H); 56.8°(V); 120.4°(D) |
|
DORI Distance |
Detect:40.0m Observe:15.87m Recognize:8.0m Identify:4.0m |
|
Illuminator |
|
|
IR LEDs |
2 |
|
IR Distance |
Up to 30m |
|
Wavelength |
850nm |
|
White LEDs |
2 |
|
Whitelight Distance |
15m |
|
Compression Standard |
|
|
Video Compression |
S+265/H.265/H.264B/H.264M/H.264H |
|
Video Bit Rate |
32k~4Mbps |
|
Audio Compression |
G.711A/G.711U |
|
Audio Sampling Rate |
8kHz/16kHz |
|
Image |
|
|
Max. Resolution |
2MP,1920×1080@25fps |
|
Main Stream |
PAL:20fps(1920×1080) NTSC:20fps(1920×1080) |
|
Sub Stream |
PAL:20fps(704×576) NTSC:20fps(704×480) |
|
BLC |
Yes |
|
HLC |
Yes |
|
AGC |
Yes |
|
3D DNR |
Yes |
|
White Balance |
Auto |
|
OSD |
Overlay of additional characters in 5 regions, 2 lines, with a maximum of 127 characters or 42 Chinese characters per region; 16*16/32*32/48*48 |
|
Feature |
|
|
Exceptions Alarm |
Disk Full; Disk R/W Error |
|
Linkage Method |
Trigger Sound; Trigger Warmlight; Trigger Recording; Trigger Capture |
|
Video Analytics |
Smart Alarm |
|
Network |
|
|
Protocols |
TCP/IP; UDP; ICMP; DHCP; DNS; NTP; IPv4; SSH; Unicast |
|
System Compatibility |
SDK |
|
Remote Connection |
≤2 |
|
Moblie Client |
EasyLive Plus |
|
Wi-Fi |
|
|
Transmission Distance |
Up tp 50m( based on actual environment) |
|
Wireless Standard |
IEEE802.11b/ 802.11g/802.11n |
|
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
|
Channel Bandwidth |
20/40MHz |
|
Wi-Fi Security |
WPA-PSK/WPA2-PSK |
|
Interface |
|
|
Built-in Mic |
Yes |
|
Built-in Speaker |
Yes |
|
Reset Button |
Yes |
|
On-board Storage |
Support microSD/microSDHC/microSDXC card,up to 256GB |
|
General |
|
|
Operating Temperature |
-10℃~50℃(14℉~122℉) |
|
Operating Humidity |
≤95%RH |
|
Storage Temperature |
-10℃~50℃(14℉~122℉) |
|
Storage Humidity |
10%~95%RH(non-condensing) |
|
Power Supply |
DC5V/2A |
|
Protection |
Surge500V; ESD6000V; IP65 |
|
Boundary Dimensions |
78(L)44W)73(H)mm |
|
Package Dimensions |
146(L)83(W)108(H)mm |
|
GrossWeight |
0.38kg |
